Product Summary
The MD27C64-20B is a 64-Kbit ultraviolet erasable programmable read-only memory. It is organized as 8K words by 8 bits per word, operates from a single +5 V supply, has a static standby mode, and features fast single address location programming. Products are available in windowed ceramic DIP packages as well as plastic one time programmable (OTP) PDIP, and PLCC packages. Typically, any byte can be accessed in less than 45 ns, allowing operation with high-performance microprocessors without any WAIT states. The MD27C64-20B offers separate Output Enable (OE) and Chip Enable (CE)controls, thus eliminating bus contention in a multiple bus microprocessor system.
Parametrics
MD27C64-20B absolute maximum ratings: (1)Storage Temperature OTP Products: –65℃ to +125℃; (2)All Other Products: –65℃ to +150℃; (3)Ambient Temperature with Power Applied: –55℃ to +125℃; (4)Voltage with Respect To VSS; (5)All pins except A9,VPP,VCC . –0.6 V to VCC + 0.5 V; (6)A9 and VPP: –0.6 V to +13.5 V; (7)VCC: –0.6 V to +7.0 V.
Features
MD27C64-20B features: (1)MD27C64-20B; (2)Fast access time; (3)Low power consumption; (4)JEDEC-approved pinout; (5)Single +5 V power supply; (6)±10% power supply tolerance available; (7)100% FlashriteTM programming; (8)Latch-up protected to 100 mA from –1 V to VCC + 1 V; (9)High noise immunity; (10)Versatile features for simple interfacing; (11)Standard 28-pin DIP, PDIP, and 32-pin PLCC packages.
Diagrams
 |
