MAX3485CSA

Transceiver, SOP, 3.3V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.17~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.17~1.50

PartNumber:: MAX3485CSA

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Maggie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-24

From Other Seller

Part Number:MAX3485CSA
US $1.17 - 1.50
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3485CSA is a 3.3V, low-power transceiver for RS-485 and RS-422 communication. Each part contains one driver and one receiver. The MAX3485CSA transmits at up to 10Mbps. Its applications are: Low-Power RS-485/RS-422 Transceivers, Telecommunications, Transceivers for EMI-Sensitive Applications, Industrial-Control Local Area Networks.

Parametrics

MAX3485CSA absolute maximum ratings: (1)Supply Voltage (VCC): 7V; (2)Control Input Voltage (RE, DE): -0.3V to 7V; (3)Driver Input Voltage (DI): -0.3V to 7V; (4)Driver Output Voltage (A, B, Y, Z): -7.5V to 12.5V; (5)Receiver Input Voltage (A, B): -7.5V to 12.5V; (6)Receiver Output Voltage (RO): -0.3V to (VCC + 0.3V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (9)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW; (10)14-Pin Plastic DIP (derate 10mW/℃ above +70℃): 800mW; (11)14-Pin SO (derate 8.33mW/℃ above +70℃): 667mW; (12)Operating Temperature Ranges: 0℃ to +70℃; (13)Storage Temperature Range: -65℃ to +160℃; (14)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3485CSA features: (1)Operate from a Single 3.3V Supply—No Charge Pump!; (2)Interoperable with +5V Logic; (3)8ns Max Skew; (4)2nA Low-Current Shutdown Mode; (5)-7V to +12V Common-Mode Input Voltage Range; (6)Allows up to 32 Transceivers on the Bus; (7)Full-Duplex and Half-Duplex Versions Available; (8)Industry Standard 75176 Pinout; (9)Current-Limiting and Thermal Shutdown for Driver Overload Protection.
