AM28F020-120JC

2 Megabit, 256 K x 8-Bit, CMOS 12.0 Volt, Bulk Erase Flash Memory, low power, 100 mA, –1 V to +1 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.40~0.70

PartNumber:: AM28F020-120JC

Brand:: Advanced Micro Devices - AMD | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Maggie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-21

From Other Seller

Part Number:AM28F020-120JC
US $0.40 - 0.70
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AM28F020-120JC is a 2 Megabit Flash memory organized as 256 Kbytes of 8 bits each. AMD Flash memory of the AM28F020-120JC offers the most cost-effective and reliable read/write non-volat ile random access memory. The AM28F020-120JC is packaged in 32-pin PDIP, PLCC, and TSOP versions. It is designed to be reprogrammed and erased in-system or in standard EPROM programmers. The AM28F020-120JC is erased when shipped from the factory. The standard AM28F020-120JC offers access times of as fast as 70 ns, allowing high speed microprocessors to operate without wait states. To eliminate bus contention, the device has separate chip enable (CE#) and output enable (OE#) controls.

Parametrics

AM28F020-120JC absolute maximum ratings: (1)Storage Temperature: –65℃ to +125℃; (2)Ambient Temperature with Power Applied: –55℃ to +125℃; (3)Voltage with Respect to Ground All pins except A9 and VPP: –2.0 V to +7.0 V; (4)VCC: –2.0 V to +7.0 V; (5)A9, VPP: –2.0 V to +14.0 V; (6)Output Short Circuit Current: 200 mA.

Features

AM28F020-120JC features: (1)High performance; (2)CMOS low power consumption; (3)Compatible with JEDEC-standard byte-wide 32-piEPROM pinouts; (4)10,000 write/erase cycles minimum; (5)Write and erase voltage 12.0 V ±5%; (6)Latch-up protected to 100 mA from –1 V to VCC +1 V; (7)Flasherase Electrical Bulk Chip Erase; (8)Flashrite Programming; (9)Command register architecture for; (10)microprocessor/microcontroller compatible; (11)write interface; (12)On-chip address and data latches; (13)Advanced CMOS flash memory technology. Low cost single transistor memory cell; (14)Automatic write/erase pulse stop timer.
