UC3844A

control IC, SOP, 30 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.30

PartNumber:: UC3844A

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Maggie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-24

From Other Seller

Part Number:UC3844A
US $0.20 - 0.30
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
CM300DY-12NF

US $63.00 - 80.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The UC3844A control IC provides the necessary features to implement off-line or DC to DC fixed frequency current mode control schemes with a minimal external parts count. Internally implemented circuits of UC3844A include a trimmed oscillator for precise DUTY CYCLE CONTROL under voltage lockout featuring start-up current less than 0.5mA, a precision reference trimmed for accuracy at the error amp input, logic to insure latched operation, a PWM comparator which also provides current limit control, and a totem pole output stage designed to source or sink high peak current. The output stage, suitable for driving N-Channel MOSFETs, is low in the off-state.

Parametrics

UC3844A absolute maximum ratings: (1)Supply Voltage (low impedance source): 30 V; (2)Supply Voltage (Ii < 30mA): Self Limiting; (3)Output Current: ±1 A; (4)Output Energy (capacitive load): 5 μJ; (5)Analog Inputs (pins 2, 3): – 0.3 to 5.5 V; (6)Error Amplifier Output Sink Current: 10 mA; (7)Power Dissipation at Tamb ≤ 25 ℃ (DIP-8): 1.25 W; (8)Power Dissipation at Tamb ≤ 25 ℃ (SO-8): 800 mW; (9)Storage Temperature Range: -65 to 150 ℃; (10)Junction Operating Temperature: -40 to 150 ℃; (11)Lead Temperature (soldering 10s): 300 ℃.

Features

UC3844A features: (1)trimmed oscillator discharge current; (2)current mode operation to 500kHz automatic feed forward compensation; (3)latching PWM for cycle-by-cycle current limiting; (4)internally trimmed reference with undervoltage lockout; (5)high current totem pole output undervoltage lockout with hysteresis; (6)low start-up current (< 0.5mA) double pulse suppression.
