Product Summary

The KID65004AF-ELP is a 7 circuit darlington transistor array.

Parametrics

Absolute maximum ratings: (1)output sustaining voltage:50V; (2)output current:500mA; (3)input voltage:-0.5V to +30V; (4)input current:25mA; (5)GND terminal current:2.8A; (6)power dissipation:0.54W; (7)operating temperature:-40℃ to 85℃; (8)storage temperature:-55℃ to 150℃.

Features

Features: (1)output current:500mA max.; (2)high sustaining voltage outputs:50V min.; (3)output clamp diode; (4)inputs compatible with various types of logic; (5)PKG type AF: FLP-16pin.

Diagrams
