IRFZ44

Power MOSFET, TO-220, 49 A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.24~0.28 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.24~0.28

PartNumber:: IRFZ44

Brand:: International Rectifier - IR | Pack: TO | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Maggie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-24

From Other Seller

Part Number:IRFZ44
US $0.24 - 0.28
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRFZ44 Advanced HEXFET Power MOSFET from International Rectifier utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that IRFZ44 is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications.

Parametrics

IRFZ44 absolute maximum ratings: (1)ID @ TC = 25℃ Continuous Drain Current, VGS @ 10V: 49 A; (2)ID @ TC = 100℃ Continuous Drain Current, VGS @ 10V: 35 A; (3)Pulsed Drain Current: 160 A; (4)PD @TC = 25℃ Power Dissipation: 94 W; (5)Linear Derating Factor: 0.63 W/℃; (6)Gate-to-Source Voltage: ± 20 V; (7)Avalanche Current: 25 A; (8)Repetitive Avalanche Energy: 9.4 mJ; (9)Peak Diode Recovery dv/dt: 5.0 V/ns; (10)Operating Junction and Storage Temperature Range: -55 to + 175 ℃; (11)Soldering Temperature, for 10 seconds: 300 ℃ (1.6mm from case ).

Features

IRFZ44 features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Fully Avalanche Rated.
