AM26S02PC

quadruple bus transceiver, DIP, –0.5 V to 7 V, –30 mA to 5 mA, high speed

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.45~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.45~2.00

PartNumber:: AM26S02PC

Brand:: Advanced Micro Devices - AMD | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Maggie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-24

From Other Seller

Part Number:AM26S02PC
US $1.45 - 2.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AM26S02PC is a quadruple bus transceiver utilizing Schottky-diode-clamped transistors for high speed. The drivers feature open-collector outputs capable of sinking 100 mA at 0.8 V maximum. The driver and strobe inputs use pnp transistors to reduce the input loading. The driver of the AM26S02PC is inverting and has two ground connections for improved ground current-handling capability. For proper operation, the ground pins should be tied together. The AM26S02PC is characterized for operation over the temperature range of 0℃ to 70℃.

Parametrics

AM26S02PC absolute maximum ratings: (1)Supply voltage, VCC: –0.5 V to 7 V; (2)Driver or strobe input voltage range, VI: –0.5 V to 5.5 V; (3)Bus voltage range, driver output off, VO: –0.5 V to 5.25 V; (4)Driver or strobe input current range, II: –30 mA to 5 mA; (5)Driver output current, IO: 200 mA; (6)Receiver output current, IO: 30 mA; (7)Operating free-air temperature range, TA: 0℃ to 70℃; (8)Storage temperature range, Tstg: –65℃ to 150℃; (9)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

AM26S02PC features: (1)Schottky Circuitry for High Speed, Typical Propagation Delay Time: 12 ns; (2)Drivers Feature Open-Collector Outputs for Party-Line (Data Bus) Operation; (3)Driver Outputs Can Sink 100 mA at 0.8 V Maximum; (4)pnp Inputs for Minimal Input Loading; (5)Designed to Be Interchangeable With Advanced Micro Devices AM26S10.
